High-Speed CMOS Quad 2-Input Exclusive-OR Gate

Product Overview

The NTE74HC86 is a high-speed CMOS gate IC featuring four independent 2-input Exclusive-OR (XOR) gates in a single package. This IC-Hi Speed CMOS gate is engineered for applications requiring rapid logic operations and minimal propagation delay, making it an ideal solution for advanced digital circuitry.

Key Specifications

• Part Number: NTE74HC86
• Logic Function: Quad 2-input Exclusive-OR (XOR) gate
• CMOS Technology: High-speed performance with low power consumption
• Package Quantity: 1 per package

Core Features

• Quad 2-Input XOR Gate configuration for versatile logic design
• CMOS construction for high speed and low power operation
• TTL-compatible logic input levels for easy integration with standard logic families

Typical Applications

• Digital logic systems requiring exclusive-OR operations
• Arithmetic circuits and parity generation/checking
• Control and data processing logic

Usage Notes

The NTE74HC86 is designed for engineers and professionals who need reliable, fast-switching XOR gates for use in a broad range of digital logic applications. Its high-speed CMOS technology ensures optimized performance for demanding systems.

This part is the equivalent replacement for the following:

1820-3007, 46-132815-3, 4822-209-73676, 482220973676, 4835-209-17004, 483520917004, 612535-0086, 6125350086, 612535-86, 74HC86, 74HC86N, 8-759-202-24, BU74HC86, CD74HC86, CD74HC86E, ECG74HC86, GD74HC86, GD74HC86B, HD74HC86, HD74HC86P, LR74HC86, M74HC86, M74HC86B1, M74HC86B1N, M74HC86P, MC74HC86, MC74HC86N, MLC74HC86, MM74HC86, MM74HC86N, NJU74HC86N, NTE74HC86, PC74HC86, PC74HC86P, SK7C86, SN74HC86, SN74HC86N, SP74HC86, SP74HC86N, TC74HC86, TC74HC86AP, TC74HC86P, UPD73HC86, UPD74HC86, UPD74HC86C
