High-Speed CMOS Inverter 74HC04 Series

High-Speed CMOS Inverter IC

The 74HC04 is a high-speed CMOS inverter designed for advanced digital and signal processing applications. With its robust CMOS technology foundation, this inverter delivers fast switching times and excellent noise immunity, making it suitable for high-performance circuit designs where reliability and efficiency are critical.

Key Features of the 74HC04 High-Speed CMOS Inverter

• Logic Family: CMOS (Complementary MetalOxideSemiconductor)
• Function: Hex inverter (6 independent inverter gates per IC)
• High-speed operation for demanding digital environments
• Low power consumption
• Strong noise immunity
• Number of Inputs: 6
• Package: Per piece (each package contains 1 IC)

Applications of 74HC04 Inverter IC

The 74HC04 CMOS inverter is commonly deployed in:

• Signal inversion and logic-level manipulation
• Oscillator and waveform generation circuits
• Buffering and logic switching
• Interface and driver stage for microcontroller and FPGA projects
• General high-speed and low-power digital applications

Technical Specifications

• Part Number: NTE74HC04
• CMOS Logic Inverter IC
• Hex (6-gate) configuration

Reliable Performance in Demanding Environments

With its high-speed switching capability and low quiescent current, the 74HC04 inverter is engineered for engineers and designers requiring consistent, dependable operation in modern electronic systems. Each unit is quality-tested to meet rigorous performance standards.

This part is the equivalent replacement for the following:

1820-2921, 319-11010, 46-754596-3, 4835-209-87304, 483520987304, 551-119-00, 612535-0004, 6125350004, 612535-4, 74HC04, 74HC04AP, 74HC04N, 8-759-202-74, CD74HC04, CD74HC04E, ECG74HC04, GD74HC04, GD74HC04B, HD74HC04, HD74HC04P, I55D4HC040, IG051000, IR004000, M74HC04, M74HC04B1, M74HC04B1N, M74HC04P, MC74HC04, MC74HC04N, MLC74HC04, MLC74HC04A, MM74HC04, MM74HC04N, MN74HC04, MSM74HC04RS, NJU74HC04N, NTE74HC04, PC74HC04, PC74HC04P, SK7C04, SN74HC04, SN74HC04N, TC40HC04, TC74HC04, TC74HC04AP, TC74HC04P, UPD74HC04, UPD74HC04C
